Aluminized Steel Truck Exhaust Bending
Our Aluminized Steel Tube’s raw material undergoes a continuous hot-dip process, building a coating across every millimeter of the surface.
Hot-dipping results in a tight metallurgical bond between layers of an aluminum-silicon alloy and the tube’s steel core.
The final aluminized tube possesses a combination of enhanced properties: the strength of steel sheathed in the corrosion resistance of aluminum and heat protection of aluminum-silicon alloy.
- Description
Description
Outside Diameter Capabilities:3125” (7.938mm) – 5.000” (127mm)
Gauge Capabilities:028″ (.711mm) – .120″ (3.048mm)
Length Capabilitie:1.25″ – 240.00″
Shape Capabilities:D-shape, Double-D, Round, Square, Rectangle, Oval, and Specialty Shapes
End Conditions:Haven Cut, Mill Cut, Saw Cut, Brushed Deburred, End facing, and Chamfering
Finishing:Re-metallizing, ID/OD scarfing to remove extruded weld bead
Aluminum Steel Tubes Exhaust Parts:
- 30 Degree Elbows
- 45 Degree Elbows
- 60 Degree Elbows
- 90 Degree Elbows
- Flex Exhaust Hoses
- Stack Pipes Chrome
- Stack Pipes Aluminized
- Clamps
- Reducers/Connectors
When purchasing exhaust components, make sure you are purchasing the correct size and that both ends are accounted for correctly.
- ID = Inside Diameter
- OD = Outside Diameter
- You can think of the tubing with the ID end as the female end of the tubing and the OD end as the male end. The OD will fit inside the ID.
Application
Aluminized steel’s heat shield makes it an ideal, cost-effective choice for fabrications exposed to punishing temperatures: automotive exhaust, plus HVAC and equipment, such as water heaters, furnaces heat exchangers, space heaters, ranges and appliances of multiple sizes. It also performs nicely against exposure to salts.
